Little Giant 551320 3-ABS 115V 60Hz 1/2" Discharge - Shallow Pan Condensate Removal Pump

3-ABS Shallow Pan Condensate Removal Pump
Designed for in-pan placement, the 3-ABS shallow pan pumps offer next generation technology for air conditioner condensate removal. Totally submersible pump with built-in, advanced non-mercury mechanical switch that automatically triggers operation when condensate in the pan or reservoir reaches a preset level. Automatic shutoff occurs when the condensate level drops. Low weight, compact size, high lift and quiet operation make the Little Giant line of ABS pumps perfect for in-pan condensate and other wastewater removal.
1/12 HP oil filled motor

Epoxy coated cast aluminum housing and motor cover

Galvanized steel tank cover

ABS tank

1 gallon tank capacity

Nylon volute

Stainless steel shaft

1/2" MNPT discharge with brass check valve for 1/2" OD, rigid plastic or copper

Viton shaft seal

Advanced non-mercury mechanical switch

Thermal overload protection

Featured Downloads

Brochures3-ABS Spec SheetType: PDFSize: 0.22 MB

3-ABS Condensate Removal Pumps ManualType: PDFSize: 0.11 MB
